Description
|
Pre-slitting Machine Model |
Available Width |
Producting Speed |
Main Power |
Number cutters |
|
LTFQ-850-3 |
800mm |
0.5~20m/min |
0.75kw |
6 Set |
|
LTFQ-1050-3 |
1000mm |
0.5~20m/min |
0.75kw |
7 Set |
|
LTZZ-1250-3 |
1200mm |
0.5~20m/min |
1.1kw |
8 Set |
|
Other Model |
we can customize machine of different specifications (machine wider ) |
|||
|
Control System |
Frequency Converters |
|||
|
Available Material |
Non-woven fabric, Wood pulp paper, Cotton paper. |
|||
|
Working Air Pressure |
6kgf/cm² |
|||
|
Voltage |
Selectable |
|||
|
Use for |
auto Tri-filter industry, hydraulic pressure, purification and water treatment industries, etc. |
|||
|
This parameter are for reference only. |
||||
Pleating Machine
Model
Available Width
Producting Speed
Available Height
Main Power
Heating Applicator
Heating plate
Available Temperature
LTZZ-150-850-6
800mm
5-160p/min
25-150mm
5.1+12kw
6unit*2lines
40-230℃
LTZZ-150-1050-6
1000mm
5-160p/min
25-150mm
5.1+16kw
8unit*2lines
40-230℃
LTZZ-150-1250-6
1200mm
5-160p/min
25-150mm
5.7+20kw
10unit*2lines
40-230℃
LTZZ-150-1550-6
1500mm
5-160p/min
25-150mm
5.7+24kw
12unit*2lines
40-230℃
Other Model
we can customize machine of different specifications (machine wider and pleat higher)
Control System
Touch Screen + PLC+Servo motor
Available Material
Non-woven fabric, Wood pulp paper, Cotton paper, iron wire fabric.
Working Air Pressure
6kgf/cm²
Voltage
Selectable
Fold Height
Full-auto adjustment .
Differences from G5
Faster than G5.
Automatic memory + automatic reset function after power failure.
The timing belt is perfectly combined with the robot.
Use for
Auto Tri-filter industry, hydraulic pressure, purification and water treatment industries, etc.
This parameter are for reference only.
|
Separate Gluing Model |
Available Width |
Producting Speed |
Available Height |
Main Power |
Glue Applicator |
||
|
Quantity Auto Gun |
Capacity Tank |
Available Temperature |
|||||
|
LTZJ-PP-100-700-3 |
650mm |
5-20m/min |
12-150mm |
16kw |
24 unit*2lines |
50kg*1unit |
40-230℃ |
|
LTZJ-PP-100-950-3 |
900mm |
5-20m/min |
12-150mm |
16kw |
36unit*2lines |
50kg*1unit |
40-230℃ |
|
LTZJ-PP-100-1000-3 |
950mm |
5-20m/min |
12-150mm |
28kw |
38unit*2lines |
50kg*2unit |
40-230℃ |
|
LTZJ-PP-100-1300-3 |
1250mm |
5-20m/min |
12-150mm |
28kw |
50unit*2lines |
50kg*2unit |
40-230℃ |
|
Specification |
|||||||
|
Control System |
Touch Screen + PLC+ Servo motor |
||||||
|
Available Material |
Cellulose/Paper, Non-woven, Synthetic Fibers,Activated carbon composite paper etc. |
||||||
|
Working Air Pressure |
6kgf/cm² |
||||||
|
Voltage |
Selectable |
||||||
|
Fold Height |
manual adjustment |
||||||
|
Use for |
Pleating & Hotmelt gluing on various Filter Materials |
||||||
|
Advatange |
1. Continuous, intermittent, misaligned glue.Save material costs. Free Adjustments of Hotmelt Beads Pattern/Position/Length 2.After-Treatment: Teflon, Anodizing, Chrome Coating, QPQ 3.Ion Blowers against Anti-Static |
||||||
