Description
|
Pre-slitting Machine Model |
Available Width |
Producting Speed |
Main Power |
Number cutters |
|
LTFQ-850-2 |
800mm |
0.5~15m/min |
0.75kw |
6 Set |
|
LTFQ-1050-2 |
1000mm |
0.5~15m/min |
0.75kw |
7 Set |
|
LTFQ-1250-2 |
1200mm |
0.5~15m/min |
1.1kw |
8 Set |
|
LTFQ-1550-2 |
1500mm |
0.5~15m/min |
1.1kw |
9 Set |
|
Other Model |
we can customize machine of different specifications (machine wider ) |
|||
|
Control System |
Frequency Converters |
|||
|
Available Material |
Non-woven fabric, Wood pulp paper, Cotton paper. |
|||
|
Working Air Pressure |
6kgf/cm² |
|||
|
Voltage |
Selectable |
|||
|
Use for |
auto Tri-filter industry, hydraulic pressure, purification and water treatment industries, etc. |
|||
|
This parameter are for reference only. |
||||
Pleating Machine
Model
Available Width
Producting Speed
Available Height
Main Power
Heating Applicator
Heating plate
Available Temperature
LTZZ-55-850-3
800mm
5-160p/min
5-55mm
2.1+6kw
3unit*2lines
40-230℃
LTZZ-55-1050-3
1000mm
5-160p/min
5-55mm
2.1+8kw
4unit*2lines
40-230℃
LTZZ-55-1250-3
1200mm
5-160p/min
5-55mm
3+10kw
5unit*2lines
40-230℃
LTZZ-55-1550-3
1500mm
5-160p/min
5-55mm
4.1+12kw
6unit*2lines
40-230℃
LTZZ-100-850-3
800mm
5-140p/min
15-100mm
2.1+6kw
3unit*2lines
40-230℃
LTZZ-100-1050-3
1000mm
5-140p/min
15-100mm
3+8kw
4unit*2lines
40-230℃
LTZZ-100-1250-3
1200mm
5-140p/min
15-100mm
3+10kw
5unit*2lines
40-230℃
LTZZ-100-1550-3
1500mm
5-140p/min
15-100mm
4.1+12kw
6unit*2lines
40-230℃
LTZZ-150-850-3
800mm
5-120p/min
25-150mm
3+6kw
3unit*2lines
40-230℃
LTZZ-150-1050-3
1000mm
5-120p/min
25-150mm
3+8kw
4unit*2lines
40-230℃
LTZZ-150-1250-3
1200mm
5-120p/min
25-150mm
3+10kw
5unit*2lines
40-230℃
LTZZ-150-1550-3
1500mm
5-210p/min
25-150mm
4.1+12kw
6unit*2lines
40-230℃
Other Model
we can customize machine of different specifications (machine wider and pleat higher)
Control System
Touch Screen + PLC+Servo motor
Available Material
Non-woven fabric, Wood pulp paper, Cotton paper, iron wire fabric.
Working Air Pressure
6kgf/cm²
Voltage
Selectable
Fold Height
Full-auto adjustment .
Advantages to G2
The height of the blade and the heating platen are automatically adjusted to control the folding height.
Lesser than G4
The opening angle of the knife and the angle of the pressing paper are not adjustable on the touch screen.
Use for
Auto Tri-filter industry, hydraulic pressure, purification and water treatment industries, etc.
This parameter are for reference only.
