Description
Specification
1、Overall output：5~15g/s design mixture ratio：A：B=100：25~35
2、Automatic shift extent on the pouring nozzle after operation：450mm
3、Maximum size on quadric automatic ladling：400×300(L×W)
4、Maximum size on circular automatic lading：Φ350mm
5、Speed of travel：2-10m/min
6、Overall power：8kw
7、Power supply：380V/50Hz
8、M/C weight：1000kg
9、M/C size：1500×2000×2100mm(L×W×H)
Features
1、Digitally-displayed gage unit program-controlled electronic operation.
2、Stable and accurate measurement self-controlled constant stuff temperature.
3、Originative construction on bucket, step less-regulation stir.
4、Novel design on nose, precise fine-turning flow inversing structure.
5、The machine designed with X-Y axial square revolving working table which can not only pour square seal pack, but also round and special seal pack.
Applications
It is mainly used to pour PU for auto air filter and industry filter.
